Bird 5010, 5010B, 5010T, & 5014 Directional Power Sensors
Bench Handling
4 drops on each face per MIL-PRF-28800F,
Class 2
Vibration
Random 10 to 500 Hz per MIL-PRF-28800F,
Class 2
Shock, Functional
30 G half-sine shock pulse per MIL-PRF-
28800F, Class 2
RoHS Compliance
Components must meet European RoHS
Directive 2002/95/EC
Assembly does not need to be RoHS
compliant
CE Compliance
61326:1997 +A1:1998 and A2:2001 – EMC
61010-1:2001 – Safety
89/336/EEC – EMC
73/23/EEC and Amendment 93/68/EEC - Low
Voltage
Salt Exposure
Salt fog tested for 48 hours, constantly
wetted with 5% salt solution at 35°C per MIL-
PRF-28800F, Class 2
Fungus Resistance
5 species for 28 days at 30°C and 95%
humidity per MIL-PRF-28800F, Class 2
Sensor Type
Bird Thruline directional two-element line
section.
Elements
APM/DPM or 43 series elements. Select two
from the same series, with RFL power 1/10 of
FWD power
Frequency Range
*
2 – 3600 MHz
Average Power Measurement, APM/DPM Elements, Forward or Reflected
Direction
RF Power Range
*
0.1 W to 1 kW
Uncertainty
†
± 5% of reading (95% c.l.)
Peak/Average
Ratio, Max
10 dB
Average Power Measurement, 43 Elements, FWD or RFL
RF Power Range
*
0.1 W to 10 kW
Uncertainty
†
± 5% of full-scale power (95% c.l.)
Peak Power Measurement, 43 Elements, FWD only
Pulse Width, Min
2 – 25 MHz15 s
25 – 100 MHz 1.5 s
> 100 MHz800 ns
Rep. Rate, Min 15 pps
Duty Cycle, Min
1 x 10
–4
