Software Interfaces
25
Terminating Power Sensor Attached
Note: Includes the Extended Frequency versions.
True Avg Power Interface
Key Button Action
Right Arrow No effect
Left Arrow No effect
Up Arrow Toggles Fwd Avg units from W to dBm
Down Arrow Toggles Fwd Avg units from W to dBm
OK Button
Initiates Shutdown.
See "Shutting Down" on
page 11
Menu Button Goes to Main Menu
Log Button Goes to Logging submenu
0 (2 Sec) Zero/Cal Unit/Sensor
8 (2 Sec) Turn On/Off Smoothing
. (2 Sec)
Performs a screen shot.
See "Performing a
Screen Shot" on page 12
Menu & Log (2 sec) Language Selection Screen
