Table 1 Video Filter Settings
Average Mode
This mode displays the average forward and reflected power.
Note: In average mode, the VSWR or system match can be dis-
played instead of the reflected power.
Peak Mode
This mode displays the peak envelope power.
Burst Mode
This mode displays the average power in a burst. The burst’s duty cycle is
measured by the DPM.
Crest Factor Mode
The crest factor is the ratio of the forward peak power and the forward average
power. It is measured in dB.
Note: There are no additional controls in this mode.
CCDF Mode
The CCDF measures the percentage of time the power level is above a
threshold. To set the power threshold:
1. Press menu.
2. Select CCDF Limit from the Main Menu.
3. Enter new value.
Video Filter Modulation Type
4.5 kHz
CW Burst (Burst width > 150 s), Voice Band AM,
FM, Phase Modulation, Tetra
400 kHz
CW Burst (b.w. > 3 s), GSM, 50 kHz AM, DQPSK
(¼, symbol rate < 24 k/s)
Full Bandwidth
CW Burst (b.w. > 200 ns), CDMA, WCDMA,
DQPSK (¼, symbol rate < 200 k/s), DAB/DVB-T
