Maintenance
59
Average Power
Match Measurement
Peak Envelope Power
Peak/Average Ratio, Max 12 dB
Measurement Uncert.
5012B
5016B
5017B
5018B
5019B
±4% of reading,
+ 0.05 Watts*
±4% of reading,
+ 0.008 Watts*
±4% of reading,
+ 0.17 Watts*
±4% of reading,
+ 0.008 Watts*
±4% of reading,
+ 0.04 Watts*
*
*. Above 35 °C or below 15 °C add 3%
Measurement Range
Return Loss
Rho (
)
VSWR
0 to 23 dB
0.07 to 1.0
1.15 to 99.9
Forward Power, Min
5012B
5016B
5017B
5018B
5019B
0.5W
0.1 Watts
1.5 Watts
0.1 Watts
0.3 Watts
Measurement Uncert.
See Figure 6 on page 60
RF Power Range
5012B
5016B
5017B
5018B
5019B
4.0 - 400 Watts
1.0 - 60 Watts
13.5 - 1300 Watts
4 - 60 Watts
2.6 - 2600 Watts
*
