Bird SiteHawk Operation Manual
35
Delete User File
Press to display the Delete User File dialog box. The Delete User File dialog bo
x
allows any one file type or all file types to be deleted from the SiteHawk. See
Figure 25
.
For procedure to delete files see
“Data Save and Export” on page 39
.
Figure 25 Delete User File dialog box
Site Name
Press to toggle ON or OFF, when set to ON the site name will be included on all
screen shots.
After Site Name is set to ON, an Edit SiteName dialog box will be displayed each
time a screen shot is taken. See
Figure 26
.
The site name must be entered the first time a screen shot is saved.
Note: The default setting for the Site Name option is OFF. If the reset
function is executed on the SK-6000, the Site Name option is reset to
OFF.
Figure 26 Site Name Dialog Box
The site name will appear at the bottom of the sweep display screen shot. See
Figure 27
.
If no site name was entered NULL will appear in place of the site name.
Figure 27 Site Name Screenshot
