CYCLOPS-I BT Scanner Configuration Guide 14
Data format of the result return sent by CYCLOPS-I to host device after executing host
command is shown as the following.
[Start][Command][,][Response][End]
Field
Format
Description
Start
RE
Starting character of response after executing
host command
Command
1 ~ 8
Response after executing host command
( among 1 to 8 )
，
Separation
Response
OK
NG
Result after executing host command ( among 1
to 8 )
YYMMDDHHMM
Date & time of CYCLOPS-I for host command
3
F
M
L
Battery status of CYCLOPS-I for host command
4
*******
Record count of data file for host command 8
End
CRLF(0x0D0A)
Stop character of response after executing host
command
Details of host command and response return value, please refer to <Host command function
list> table as follow.
Command 5 ~ 8 is used while CYCLOPS-I is in waiting state of <Bluetooth Data Transmit
Mode>.
Host Command function list table
No
Function
Host Sends
Host Receives
Notes
1
SCAN
!1<CRLF>
RE1,OK<CRLF> and
<data>
RE1,NG<CRLF>
CYCLOPS-I will scan when
this host command be
executed, CYCLOPS-I will
return scan result and scanned
data according to SPP data
transfer format.
2
Set Date and
Time to
CYCLOPS-I
!2YYYYMMDDHH
MM<CRLF>
RE2,OK<CRLF>
RE2,NG<CRLF>
Date & Time of CYCLOPS-I
will be set according to this
command.
