4. LED Indicators and Buzzer Sound
The follow table gives the description of LED indicators and buzzer sound on different
events.
Device Status
SCAN LED
Charging LED
Bluetooth LED
Sound
Successful Scan
Green (50ms)
Bi
Scan Failed (5-sec
decoding time out)
Red (300ms)
Bi, Bi, Bi
Successful
Configuration Scan
Green
(100ms)
Bi~, Bi
Failed Configuration
Scan (5-sec time out)
Red(300ms)
Bu, Bu, Bu
“SPP Slave Mode”
Set
Bu, Bu
“SPP Master Mode”
Set
Bi, Bi
“HID Mode” Set
Bu, Bi
“Real-Time Mode
Power-Up”
Green
“Batch Mode
Power-Up”
Red
“DO NOT RESET
RTC” when
Power-Up (Batch
Mode)
Orange Flash
On：300 ms
Off：500 ms
3 Times
Bu~,Bu~,Bu
~
(WARNING
sound)
“Data Record Found
in Data File” When
Power-Up
Green Flash
On：300 ms
Off：500ms
3 Times
Memory Full
Red Flash
On：300 ms
Off：500ms
3 Times
Bu~, Bu~
(WARNING
sound)
“DELETE One
Record in Data File”
Successful
Orange
Bi, Bi,
