B-3 General Specifications
General Items Specifications
Warm up time At least 30 minutes
Temperature Coefficient
Add 0.15 x (the applicable accuracy)/°
°°
°C at 0°
°°
°C to 18°
°°
°C and
28°
°°
°C to 50°
°°
°C
Operating Temperature
0°
°°
°C to 50°
°°
°C (32°
°°
°F to 122°
°°
°F)
Storage Temperature
-20°
°°
°C to 60°
°°
°C
Altitude Up to 2000 M
Pollution Degree II
Over-voltage Category CAT II-600V and CAT I-1000V
Relative Humidity
! Up to 80% for 0°
°°
°C to 28°
°°
°C (75% RH for 12MΩ
ΩΩ
Ω and above
ranges of resistance measurement)
! Up to 70% for 28°
°°
°C to 35°
°°
°C
! Up to 50% for 35°
°°
°C to 50°
°°
°C
Common Mode Voltage
1000V dc or peak ac rms maximum between any input and
earth ground
Dimension Approx. 255(w) x 105(h) x 305(d) mm (with holsters)
Weight <3.0kgs
Line Voltage
100V / 120V / 220V / 240V ac ±
±±
±10%, 50/60Hz, 16VA maximum
Interface
RS-232 (DB-9, male connector)
! Baud rates: 9600, 4800, 2400, 1200, 600, 300
! Data length: 7 or 8 bits
! Parity: even / odd / none
! Stop bit: 1 or 2 bits
! Echo: on / off
! Print mode: on / off
Safety Requirement Designed in compliance with EN61010-1 (IEC1010-1)
Installation Category
CAT-I 750VAC/1000VDC or CAT-II 600V,Pollution Degree 2
Environment
EMC Requirement Designed in compliance with EN61326-1.
