! Standard Event Status Enable Register ( ESE )
The Standard Event Status Enable Register is a mask register that allows the host
to enable or disable (mask) each bit in ESR. When a bit in the ESE is 1, the
corresponding bit in the ESR is enable. When any enabled bit in the ESR changes
from 0 to 1, the ESB summary bit (bit 5) of the STB register also goes to 1.
Use *ESE to write to this register and *ESE? to read this register.
! Operation Event Register
The Operation Event Register assigns specified event to specific Operation Event
Status Register bits.
Operation Status Register:
Bit 9 to 15 Bit 8 Bit 7 Bit 6 to 5 Bit 4 Bit 3 to 0
0 2ND Compare 0 Measuring 0
Bit 0 - 3 are not used.
Bit 4 (Measuring) is set as 1 when the meter is at the end of a measurement cycle.
Bit 5 - 6 are not used.
Bit 7 (Compare) is set as 1 when the meter is operating in the compare mode.
Bit 8 (2ND) is set as 1 when the meter is operating in the dual display mode.
Bit 9 -15 are not used.
Note: Use *CLS to clear event registers.
