91
Appendix A
5492 Specifications
A-1 Introduction
Appendix A describes the complete specifications of the 5492 5 1/2 Digit Dual
Display Multimeter.
A-2 Technical Specifications
! Specifications assumptions:
• One-year calibration cycle.
• Operating temperature at 18°C to 28°C (64.4°F to 82.4°F).
• Accuracy is expressed as: ± (% of reading + digits) after 30 minutes warm-up.
• Temperature coefficient: Add ± [0.15 x (the applicable accuracy)/°C] for 0°C to
18°C and 28°C to 50°C.
• Relative Humidity (RH) up to 80% for 0°C to 28°C (75% RH for 12MΩ and
above ranges of resistance measurement); up to 70% for 28°C to 35°C; up to
50% for 35°C to 50°C
• All specifications are specified under single display mode in operation only.
!
Display Counts and Reading Rates
Full Scale Display Counts
Slow Medium Fast
119,999 39,999 3,999
Reading Rates on Single Display (Readings/Sec)
Measurement Functions Slow Medium Fast
DCV 2 5 20
DCA 2 5 20
Diode 2 5 20
ACV 2 4.2 20
ACA 2 4.2 20
2-wires Ω
ΩΩ
Ω
2 4 17
4-wires Ω
ΩΩ
Ω 4MΩ
ΩΩ
Ω/1.2MΩ
ΩΩ
Ω range and below
0.6 0.8 0.9
4-wires Ω
ΩΩ
Ω 12MΩ
ΩΩ
Ω range and above
1.4 1.7 1.9
Frequency 1.2 1.7 2.4
ACV+DCV 0.4 0.5 0.7
ACA+DCA 0.4 0.5 0.7
