22
1. Power Switch 6. Secondary Display Button
2. Measurement Function Buttons 7. Local / Setup Button
3. Range / Comparator Buttons 8. Reading Rate Button
4. Calibration Mode Button 9. Arithmetic Function Buttons
5. Shift Key 10. Hold/Reference Imped. Button
Figure 3-3 Front Panel Pushbuttons
Table 3-3 Range Scale Value in Slow Reading Rate
Function Range Scale Auto Ranging
120mV, 1.2V, 12V, 120V, 1000V
•
••
•
, +
120mV, 1.2V, 12V, 120V, 750V
•
••
•
, , +
12mA, 120mA, 1200mA
(1)
•
••
•
, , +
12A
(2)
Manual only
Hz 1200Hz, 12kHz, 120kHz, 1MHz
•
••
•
2WΩ
ΩΩ
Ω, 4WΩ
ΩΩ
Ω
(3)
120, 1.2k, 12k, 120k, 1.2M, 12M, 120M Ω
ΩΩ
Ω
•
••
•
1.2V Fixed range
.
2W / 120 Ω
ΩΩ
Ω (Continuity Mode)
Fixed range
(1)
1200mA for 5492 only.
(2)
10A dc or ac rms continuous; 12A dc or ac rms for 30 seconds maximum.
(3)
In order to eliminate the noise interference, which might be induced to the test leads,
it is recommended to use a shielded test cable for measuring resistance above
120KΩ
ΩΩ
Ω.
2 3 8 10 7 9 6 5 1
4
