57
Table 6-7. Descriptions for SH Command
Syntax Description
SH<s><nnnnnn>
SH command is used to set high limit in counts for compare function.
<s> is a sign symbol for the high limit, can be set as “+” or “-“.
<nnnnnn> is a six-digit decimal number from “000000” to “199999”.
Example: “SH+102345”
Rate Range High limit to be
Slow 120.000 V +102.345V
Medium 400.00V +1023.45V
Fast *1 400.0V +1023.4 V
Notes:
1. The least setting digit is blank on the display of meter, but it still uses to compare function. To set
least setting digit to “0” for fast mode as necessary.
Table 6-8. Descriptions for SL Command
Syntax Description
SL<s><nnnnnn>
SL command is used to set the low limit in counts for compare (COMP)
function.
<s> is a sign symbol “+” or “-“.
<nnnnnn> is a six-digit decimal number from “000000” to “199999”.
Example: “SL-098765”
Rate Range Low limit to be
Slow 120.000 V - 98.765V
Medium 400.00V - 987.65V
Fast *1 400.0V - 987.6 V
Notes:
1. The least setting digit is blank on the display of meter, but it still uses to compare function. To set
least setting digit to “0” for fast mode as necessary.
