! DC Voltage
Resolution, Full Scale Reading and Accuracy
Rate
(1)
Range Resolution
Full Scale
Reading
Accuracy
(1 year)
Typical Input
Impedance
(4)
S
120mV
1.2V
12V
120V
1000V
1µ
µµ
µV
10µ
µµ
µV
100µ
µµ
µV
1mV
10mV
119.999
1.19999
11.9999
119.999
1000.00
(3)
0.012% + 8
(2)
0.012% + 5
0.012% + 5
0.012% + 5
0.012% + 5
10.0MΩ
ΩΩ
Ω
10.0MΩ
ΩΩ
Ω
11.1MΩ
ΩΩ
Ω
10.1MΩ
ΩΩ
Ω
10.0MΩ
ΩΩ
Ω
M
400mV
4V
40V
400V
1000V
10µ
µµ
µV
100µ
µµ
µV
1mV
10mV
100mV
399.99
3.9999
39.999
399.99
1000.0
(3)
0.012% + 5
0.012% + 5
0.012% + 5
0.012% + 5
0.012% + 5
10.0MΩ
ΩΩ
Ω
11.1MΩ
ΩΩ
Ω
10.1MΩ
ΩΩ
Ω
10.0MΩ
ΩΩ
Ω
10.0MΩ
ΩΩ
Ω
F
400mV
4V
40V
400V
1000V
100µ
µµ
µV
1mV
10mV
100mV
1V
399.9
3.999
39.99
399.9
1000
(3)
0.012% + 2
0.012% + 2
0.012% + 2
0.012% + 2
0.012% + 2
10.0MΩ
ΩΩ
Ω
11.1MΩ
ΩΩ
Ω
10.1MΩ
ΩΩ
Ω
10.0MΩ
ΩΩ
Ω
10.0MΩ
ΩΩ
Ω
(1)
Rate: S (Slow), M (Medium), and F (Fast).
(2)
Use relative (REL) modifier.
(3)
In Vdc 1000V range, 5% over-range (1050Vdc) is readable.
(4)
Input Impedance is in paralleled with capacitance <120pF.
•
••
• Maximum input voltage: 1000Vdc or peak ac on any range
•
••
• Response Time: Approximately 1.0 second when the displayed reading reaches 99.9% dc
value of the tested input signal at the same range.
Note: When voltage (ac+dc) measurement function is selected, the Vdc input impedance is
paralleled with an ac-coupled 1.1M
Ω ac divider.
Noise Rejection Ratio
Rate
CMRR
(1)
NMRR
(2)
S / M / F
>90dB at dc, 50/60Hz ± 0.1%
(1k
Ω
ΩΩ
Ω
Unbalanced)
>50dB at 50/60Hz ± 0.1%
(1)
CMRR is the Common Mode Reject Ratio
(2)
NMRR is the Normal Mode Rejection Ratio
