3.5 Initialization of Measurement Conditions
! Power up default configuration Status:
When turning the meter on, it assumes its power-up configuration. The
power-up configuration set at the factory is shown in Table 3-2.
As configuration data for IEEE-488 address, RS-232 baud rate, data bit, stop
bit, parity, and echo are stored in the non-volatile memory, they are not
changed when power is cycled off and on until the configurations are
changed by the user.
Table 3-2 Default configuration Status
Parameters Default Settings
Function DCV
Range Auto Range
Hold OFF
Reading Rate Slow Mode (120,000 Counts)
Arithmetic Function OFF
Hi: 199999 (199999E+0)
Comparator
Lo: 000000 (000000E+0)
REFΩ
ΩΩ
Ω (Reference Impedance) 600 Ω
ΩΩ
Ω
Constant
Rel # (Relative Base) 000000E+0
Secondary Display mode OFF
CAL mode OFF
3-6 Selecting A Measurement Function
Press a function button shown in Figure 3-3, to select a measurement function.
To select ac + dc total true RMS readings, press and or and
, simultaneously.
When user selects a function, annunciator turns on to indicate the function
selected. If the secondary display has been selected and the 2ND function
annunciator remains on when a function button is pressed, the secondary display
will display the reading taken from the new measurement function selected.
The summary of ranges and scale values are shown in Table 3-3 and Table 3-4
for slow rate and medium/fast rate respectively.
