Reading Rates on Dual Display (Readings/Sec)
Measurement Functions Slow Medium Fast
DCV / ACV 0.7 1.0 1.9
DCA / ACA 0.7 1.0 1.9
DCV / DCA 0.7 1.0 1.9
DCV / ACA 0.2 0.2 0.5
ACV / ACA 0.2 0.2 0.5
ACV / DCA 0.7 1.0 1.9
ACV / Frequency 0.5 0.7 1.1
ACA / Frequency 0.6 0.8 1.3
ACV+DCV / DCV 0.5 0.6 0.9
ACA+DCA / DCV 0.1 0.2 0.4
ACA+DCA / ACV 0.1 0.2 0.4
ACA+DCA / DCA 0.5 0.6 0.9
dBm(ACV) / Reference Ω
ΩΩ
Ω
2.1 4.2 11.9
dBm(ACV) / ACV 0.7 1.0 1.7
dBm(ACV) / DCV 0.6 1.0 1.7
dBm(ACV) / Frequency 0.7 1.0 1.7
Note 1: Above table shows some common combinations and applications of
using dual display.
Note 2: Using RS-232 or GPIB remote interface, the reading rate
approximates to normal mode.
