Section 4
Measurement Application Examples
4-1 Introduction
Section 4 describes some advanced features and applications that help the user to
operate the meter more effectively. The user must be familiar with the basic
measurement operations described in Section 2 and Section 3 and has a basic
understanding of electronics knowledge.
4-2 Applications for Using Dual Display
The dual display capability is one of the most useful features provided with the
meter. User may take the advantages to greatly enhance the test and
measurement capabilities.
Some common combinations and applications of using dual display are provided
in Table 4-1.
Table 4-1. Typical Combinations and Applications for Using Dual Display
Primary
Display
Secondary
Display
Applications
Vdc Vac
Vac+Vdc Vdc
•
••
• Testing DC to AC or AC to DC converter circuit
•
••
• Measuring DC level and AC ripple of power supply
Vdc Adc
•
••
• Testing power supply load regulation
Vdc Aac
•
••
• Checking loop current and voltage drop level
Aac+Adc Vdc
•
••
• Testing line and load regulation
Vac Adc
•
••
• Testing AC to DC or DC to AC converters
Aac+Adc Vac
•
••
• Measuring DC level and AC ripple of power supply
Vac Aac
•
••
• Testing transformer
Vac Hz
•
••
• Measuring AC frequency response of amplifier circuit
Aac Hz
•
••
• Adjusting AC motor control
Adc Aac
Aac+Adc Adc
•
••
• Measuring AC ripple and DC current of power supply
•
••
• Measuring current dissipation for power supply analysis
dBm
Reference
Ω
ΩΩ
Ω
•
••
• Setting dB reference impedance and show dBm
dBm Vdc
•
••
• Indicating DC voltage and dBm
dBm Vac
•
••
• Indicating AC voltage and dBm
dBm Hz
•
••
• Checking frequency response
