5-4 Recommended Test Equipment
The test equipment requirements listed in Table 5-1 or equivalents are required to
perform the calibration and performance verification test procedures. Alternative
equipment may be used as long as the accuracy is at least as good as those listed.
Table 5-1 Standard Equipment Requirements
Standard
Source
Operating
Range
Accuracy
Required
Recommended
Equipment
DC Voltage
Calibrator
Range, 0 to 1000VDC ≤
≤≤
≤ ± 0.002%
Fluke 5520A or
equivalent
AC Voltage
Calibrator
Range, 0 to 750V, 1kHz ≤
≤≤
≤ ±- 0.03%
Fluke 5520A or
equivalent
10mA to 100mA ≤
≤≤
≤ ± 0.01%
DC Current
Calibrator
1A to 10A ≤
≤≤
≤ ± 0.03%
Fluke 5520A or
equivalent
10mA to 1000mA, 1kHz ≤
≤≤
≤ ± 0.1%
AC Current
Calibrator
1A to 10A, 1kHz ≤
≤≤
≤ ± 0.2 %
Fluke 5520A or
equivalent
100Ω
ΩΩ
Ω, 360Ω
ΩΩ
Ω, 1kΩ
ΩΩ
Ω, 3.6k,
10kΩ
ΩΩ
Ω, 36kΩ
ΩΩ
Ω, 100kΩ
ΩΩ
Ω,
360kΩ
ΩΩ
Ω, 1MΩ
ΩΩ
Ω, 3.6MΩ
ΩΩ
Ω
≤
≤≤
≤ ± 0.01%
Fluke 5520A or
equivalent
10MΩ
ΩΩ
Ω, 20MΩ
ΩΩ
Ω, ≤
≤≤
≤ ± 0.05%
Resistance
Calibrator
100MΩ
ΩΩ
Ω, 200MΩ
ΩΩ
Ω ≤
≤≤
≤ ± 0.5%
Fluke 5520A or
equivalent
Audio Level
Generator
1V/1000Hz ≤
≤≤
≤ ± 0.001%
Fluke 5520A or
equivalent
