Note : SCPI stems from IEEE488.1 and IEEE 488.2. Although the IEEE 488.2 standard
addressed some instrument measurements, it principally dealt with common commands and syntax
or data formats. Please refer to the IEEE488.2 and SCPI reference manual for more information.
7-4-2 Response Message Data Types
Response messages are data from the meter to a computer in response to a query. A
query is a command followed by a question mark. Table 7-2 contains explanations
of data types.
Table 7-2. Response Message Data Types
Data Type Explanations Examples
<NR1> An integer
+100000, -10000,
123, -100
<NR2>
This numeric representation has an explicit radix
point
+13.23455, -.00002,
3.45678
<NR3>
This representation has an explicit radix point and
an exponent.
+1.2E+2, +0.1E+0,
-0.12E-3, 9E+9
<numeric value> Accepts <NR1>, <NR2> and <NR3> data types.
<NRf>
Flexible numeric representation
(only positive integers).
100, 255, 16
<Boolean>
A single ASCII-encoded byte, is return for the
settings query.
0 or 1,OFF or ON
<literal>
ASCII-encoded bytes corresponding to the short
form of the literal used as the command parameter.
SLOW, MID, IMM,
BUS, DC, AC
