24
Recording State
This is the default mode when static recording is enabled. In this mode, LCD will display “MAX
AVG MIN” indicator. In a relatively stable range of test data, a beep tone will sound once a
recording has been stored.
NOTE: When the data fluctuation range is higher than 1%, data record will dynamically be
refreshed.
Maximum Display
Press the button until the “MAX” indicator is shown on the display. This indicates that
the value in the primary display represents the recorded maximum value.
Minimum Display
Press the button until the “MIN” indicator is shown on the display. This indicates that
the value in the primary display represents the recorded minimum value.
Average Display
Press the button until the “AVG” indicator is shown on the display. This indicates that
the value in the primary display represents the recorded average value.
Disable Static Recording
To exit this mode, press and hold the button for two seconds. The “MAX AVG MIN”,
“MAX”, “MIN”, or “AVG” indicator will disappear on screen.
NOTE: Changing the type of test parameters will automatically turn off static recording.
Calibration (CAL)
This mode is used when the user wants to “zero” the meter based on a reference value or
wants to obtain a reading that is relative to a reference value.
For example, if test leads are going to be used in a measurement, the user may want to set a
reference with the test leads inserted into the input terminals so that any measurements taken
will not take into account the test leads.
