BK Precision 880 - Resistance Measurement Details

58
Charge Time and Current
(typical)
Max.: 160min. Max. Current: 100mA
Operating Current (with
backlight off)
Max.:35mA
Typical:25mA (@1kHz, 0.6 Vrms,100Ω load)
Standby Current (Power
Off)
Max. :11μA (typical)
Power Requirements
1) DC 9V Battery
2)Ext. AC Adapter: DC
12 Vmin –15 Vmax.
(Load 50 mA Min.)
Operation Condition
Temperature
0℃ -- 40℃
Relative Humidity
≤90% R.H.
Storage Temperature
-4 ° F to 104 °F (0 °C to +50 °C); 0-90 % R.H.
Dimensions (L/W/H)
7.5 x 3.5 x 1.6”
190mm *90mm *41mm
Weight
0.7 lbs. (350 g)
Accuracy Specifications
Testing Conditions:
1． Environnent temperature：23℃±5℃; Humidity: ≤75% R.H.
2． Valid after 10 minutes of warm up time.
3． Test in measuring slots on front panel.
4． Measurements performed after correct open and short correction.
5． Test in the recommended equivalent mode.
6． Accuracy Indication: ± (% reading + number of least significant digits）
7． If the actual measurement exceeds the display range indicated in the table below, the
accuracy is not specified
8． When selecting a 0.3V test level, double the accuracy in the tables below
9． Subscript Explanation:
S—series equivalent; p—parallel equivalent;
e: accuracy.
