27
3. Press when finished making the selection.
4. Press several times to exit the menu.
Select Source Type
For external voltage and current programming of the output, users can configure the power
supply to be controlled with external DC voltages or resistances. Follow the instructions below
to select the source type.
1. From the CONFIG menu, browse and select Ext-Ctrl and press . The following
screen will display:
2. Select the third item V-P or R-P so that it is blinking. Use the keys to change
between V-P or R-P.
V-PUse external DC voltage source for programming the output.
R-PUse external resistance for programming the output.
3. Press when finished making the selection.
4. Press several times to exit the menu.
Enable/Disable External Analog Control
If external analog control is not used, it must be disabled before normal front panel operation
can resume. Follow the steps below to enable or disable external analog control.
1. From the CONFIG menu, browse and select Ext-Ctrl and press . The following
screen will display:
Ext Ctrl Setup
10v-M 10v/10k-P V-P Off
Ext Ctrl Setup
10v-M 10v/10k-P V-P Off
