OCTOBER 16, 2007 22 DFG-100/200
BURNER & PIPING, EXPLODED
Ref. Part
No. No. Description
1 18799 Burners, Steel Tube Set of 2
Units after 01/86
2 19097 Burners, Steel Tube Set of 2
Units before 02/86, Not for use with IID
8717 Orifice, Main Burner Set of 2, Specify gas type & model
21079 Secondary Air Duct (Set of 2)
3 90063 Shutter Only, Air
4 3001 Locknut, Air Shutter
5 15871 Manifold Assy
6 33249 Tubing, Manifold Flex Hose
ONLY Units after 02/86
7 90023 Tubing, Manifold Flex Hose, w/fittings Units before 02/86
NOTE: The solid manifold tubing has been converted to a flexible
tubing. 90023 comes w/all necessary parts to use the flex tubing.
18414 Bracket, Ignitor
Units between 07/84 & 02/86
20357 Shield, Ignitor
Units between 07/84 & 02/86
8 17515 Ignitor w/ Bracket, Replacement
Units before 02/86 Hot Surface Ignition
34689 Capacitor Assy, Snubber
Units after 01/05/99 or S.N. 010599RA027T
NOTE: ALL PARTS LISTED BELOW ARE FOR UNITS
AFTER 01/86 WITH SPARK IGNITION
18792 Mounting Plate, for Spark Box
9 18584 Pilot Burner, Complete, Nat
9 18585 Pilot Burner, Complete, LP
18256 Flame Sensor Probe, Only
19677 Wire, Flame Sensor
18263 Orifice, Pilot, Nat
18257 Orifice, Pilot, LP
20195 Spark Gap Gauge
To Next Page
