M6*12 screw(Fix bracket-wall screw)
M5*10 screw
(4 fixed bracket-machine, 2 PV ground)
M4*10 screw
(Fix the decorative covers on both sides)
M8*60 Expansion bolt(Wall screw)
RNB3.5-5S TO terminal
AC connection terminal *10PCS
PV ground *2PCS
Battery power cable +
22
23
24
1
2
1
2
1
25
26
IOT Controller
Battery power cable -
Expandable rubber stopper
M3 tapping screws(KA3*25)
IOT Controller mounting bracket
To Next Page
