Before installation and maintenance , make sure neither the AC side nor the DC
side is electrified. For a period of time after the inverter is electrified and discon-
nected , the capacitor is still electrified , so it is necessary to wait treat 30 minutes
to ensure that the capacitor is fully discharged. If it is not used as required, it may
cause safety hazards.
3.Electrical connection of EP600 energy storage system
Danger
Warning
Always turn off the DC switch before making electrical connec-
tions on the DC side.
All installation operations must be performed only by professional
authorized personnel.
The specification of cables used in the Energy Storage System
must be proper, with strong connections and good insulation.
Incorrect wiring may cause damage to the product, which will not
within the warranty .
Figure 2-7
Ground
Wall
B500
Base
B500
EP600
