1. Install brake cables at the brake levers and pass cable
completely through the housing
2. Install Stoppers on the cable ends exactly 32mm from the end
of the ferrule (ensure the brake cable is taut for accurate
measurement)
3. Tighten the Stopper Bolts to 3Nm
4. Trim remaining cable
Brake Housing & Cable Installation
Housing
Ferrule
Stopper
32mm
Brake Lever Brake Booster
