BMPRO BatteryPlus35SR - Mounting

11
11
Figure 1: Recommended Mounting Holes
Mains Cable
Output Cables
Mounting Holes (x4)
Countersunk screw
Recommended
50mm
screw slot
MIN 10mm
Gap required
At all times
Figure 1: Recommended Mounting Holes
Mounting
BatteryPlus35 should be securely mounted to a suitably strong surface, using 4 pre-
drilled mounting holes. Dimensional details are provided in Figure 1 below.
