Remote Load-Isolator Switch Connection
BatteryPlus35 allows for remote control of the load connections by two methods,
remote switch via the Trek display (optional accessory) and hardware remote switch
terminals. All loads can be turned off by operation of either switch. This feature can
be used to store the caravan when not used.
Both methods are described below. If both methods are installed, the dedicated
remote switch overrides the remote switch via Trek.
Remote Switch via Trek Display
The load outputs on BatteryPlus35 can be controlled via Trek (purchased
separately). Trek has a dedicated button to switch all loads off and on. When the
loads are OFF the unit enters into ECO mode.
Battery charging is not affected by this switch.
For detailed information and more, see page 31.
Note: This function is not available on the RVView.
Remote Switch via Hardware Remote Switch Terminal (RSW)
A pair of contacts, item in Name and Function of Parts, are provided for
connection to the external switch. When this switch is shorted, all loads are
disconnected from all power and the unit is put into storage mode.
Battery charging is not affected by this switch.
Any accessories connected to the communication bus are turned off.
Any convenient switch and wire size may be used.
Communication Bus Connection
The communication bus connection is used to connect the BatteryPlus35 and
external BMPRO accessories via a data cable.
Note: See the BMPRO by Setec website for cable accessories.
Installing Controllable Pumps
The BatteryPlus35 has a feature which enables two output channels to be remotely
controlled from the Trek unit. These outputs are used to control two pumps which
can only be switched ON and OFF, if installed. The pumps have to be connected to
outputs and . If only one pump is required to be controlled, connect it to output
Figure 3: DC Wiring Diagram for BatteryPlus35SR and BatteryPlus35HA and Figure
4: DC Wiring Diagram for BatteryPlus35PM shows a single pump connected.
7
7
9
1313 14
