Input Voltage Range: 100VAC to 240 VAC nominal, ±10%, 50-60 Hz
Input Surge: < 40 A (cold start)
Output Current: 35A Continuous (load + battery current)
Factory Set Voltage: 13.65 V (float voltage)
Output Ripple Voltage: <150 mV
BatteryPlus35SR/PM
Battery Current Limit:
20 A max
BatteryPlus35HA
Battery Current Limit:
30 A max
Battery Connect:
12.8 ± 0.2 V (after LVD event) Lead-Acid
13.8 ± 0.2 V (after LVD event) LiFePO4
Low Voltage Disconnect:
10.5 ± 0.2 V Lead-Acid
12.0 ± 0.2 V LiFePO4
Battery Drain after LVD: < 15 mA
AC/DC Efficiency: > 83 %
Cooling Fan: Thermally controlled
BatteryPlus35SR/HA
Solar Output Current:
30A (nominal)
BatteryPlus35SR/HA
Solar Start Voltage
17.5V
BatteryPlus35SR/HA
Solar Input Voltage
15V to 25V (after start-up)
Ambient: 0°C – 50°C
Communication: Communication bus available
Weight: 2 kg
Standards:
Safety: IEC60335-2-29, IEC62109-1,
EMC: CISPR 14, Approvals: RCM,
SPECIFICATIONS
