BMPRO BatteryPlus35SR - Page 17

17
Output 13 Pump 1 Output 14 Pump 2 Output 1 Persistent output, on even if battery button on Trek is pushed
Figure 4: DC Wiring Diagram for
BatteryPlus35PM
17
Mains Cable
MIN 10mm
Gap required
At all times
NEG OUTPUTS POS OUTPUTS
AUX
- +
BATT
- +
Load
ISO
SW
1 2 3 4
5
6
7
8 9 10 11 1213 14 1 2 3 4
5
6
7
8 9 10 11 1213 14
F
U
S
E
3
0
A
TV or
Lights or
Radio etc..
Water Pump
Battery Negative must not be connected to chassis
Chassis
Solar
+
-
Batt
+
-
External Solar
Controller
Output 13- Pump1 Output 14 – Pump2 Output 1 – Persistent output, on
even if battery button on
the Trek is pushed
Figure 4: DC Wiring Diagram for BatteryPlus35PM
BatteryPlus35PM
