36
Setup Mode Indicators
These indicators only appears when Trek is in setup mode. The icons indicate the
functions of the buttons adjacent to it. The icons include edit, back, & symbols.
Battery Off
This indicator is displayed when loads are disconnected from all sources including
the battery. This is controlled by the battery isolate button and in conditions
where the battery is too low to be used. All other segments will also be turned off to
reduce current draw from the battery.
Battery Low
This indicator is displayed when the battery voltage is at or below the low voltage
warning threshold. For lead-acid battery the default is 11V and for LiFePO4 it is
12.3V. It is recommended to charge the battery if this annunciator is seen.
This is user configurable, refer to the Setup Mode section.
AC connected
This indicator appears only when BatteryPlus35 is connected to AC mains.
Volts
Displays the battery voltage.
The displayed value will flash if communication with an installed the BC300
(External Shunt) is lost. Refer to Appendix 1 to disable flashing.
Amps
Shows the charging or discharging current of the battery.
The displayed value will flash if communication with an installed the BC300
(External Shunt) is lost. Refer to Appendix 1 to disable flashing.
Clock
Displays a 12 or 24 hour clock. This is user configurable. Refer to the Setup Mode
section.
12
13
11
14
15
17
19
18
