BMT 965 - Pressure

OZONE ANALYZER BMT 965 Manual, Rev. 01/2024
___________________________________________________________________________
23
M965_001_EN_2023
-
11
-
01
 %wt(air) (carrier gas air)
If the concentration unit is changed the range will change, too:
g/Nm
3
(g/m
3
, ppm
w
)
% wt/wt or
%wt(air)
ppm
v
Range-ID
2.000 0.1500 1000 1
5.000 0.3500 2500 2
10.00 0.7000 5000 3
20.00 1.500 10000 4
50.00 3.500 25000 5
100.0 7.000 50000 6
150.0 11.00 75000 7
200.0 14.00 100000 8
300.0 20.00 150000 9
400.0 26.00 200000 10
0.750 0.0600 375.0 11
15.00 1.100 7500 12
500.0 31.00 250000 13
600.0 37.00 300000 14
0.500 0.0400 250.0 15
Please bear in mind, that there is a non-linear relationship between g/Nm
3
and
ppm
v
on one side and %wt/wt resp. %wt(air) on the other side. Also, the full range
concentrations are not exactly the same upon switching, as the range limits are
rounded values.
Note: Accordingly, the analog outputs may change, when the ozone concentration
unit is changed.
Furthermore, the thresholds of High & Low Alarm are recalculated automatically.
For a complete list of available ranges, please refer to the latest order sheet.
Pressure
The unit of absolute pressure shown on the display can be changed from bar to psi,
Torr or MPa. Here are some examples for recalculation of pressure range when
changing the unit:
bar
psi
Torr
MPa
1.15 16.68 863 0.115
1.5 21,76 1125 0.150
2.0 29.02 1500 0.200
2.5 36.27 1875 0.250
3.0 43.52 2250 0.300
3.5 50.78 2625 0.350
4.0 58.03 3000 0.400
For a complete list of available ranges, please refer to the latest order sheet.
