OZONE ANALYZER BMT 965 Manual, Rev. 01/2024
___________________________________________________________________________
47
Appendix C: Cabinet Version BMT 965C
General description
The OZONE ANALYZER BMT 965C (cabinet version) is housed in a splash-proof IP 65
(NEMA 4X) aluminium cabinet. It is NRTL safety certified by TUV Rheinland of North America.
It is also certified according to IACS E10 and USCG 46 CFR 612.060-30 for operation in ballast
water treatment systems on ships. It is equipped with everything necessary for fully automatic
stand-alone operation.
Fully automatic means: A purge unit is provided which consists of a three-way solenoid valve, and
an air pump (with particle filter), both being controlled by the timer of the analyser. The system
automatically purges the cuvette with clean, filtered air, and then zeroes the analyser. The zeroing
interval may be chosen between 1 and 99 hours (see page 15).
Stand-alone means: A sample gas filter is provided (external to the cabinet), a throttle valve and a
flow meter (behind the front door), and a Catalyzing Cartridge (external). An external Dirt Trap to
remove namely fluidic dirt before it can reach the analyser, may be provided on request.
Dimensions of the cabinet are 300 x 200 x 120 mm (W x H x D), the space needed (door open,
sample gas tubing and cables connected) is approx. 480 x 240 x 420 mm, and the weight is about
5.5 kg. The cabinet can be wall mounted using the four brackets provided at the rear (four mount-
ing holes are 6 mm ID, spaced 240x225 mm).
