FUSES 13, 14, AND 15
0670.3Ć
1998
03
FUSE DETAILS
P90
FRONT POWER
DISTRIBUTION BOX
A104
BODY
ELECTRONICS
CONTROL MODULE
(ZKE IV)
1 GE/BR
E26
LEFT FOG LIGHT
A2w
INSTRUMENT
CLUSTER
8 X17
.75 GE/BR
6312.0
1 GE/BR
E27
RIGHT FOG LIGHT
NSW
10 X10016
1 GE/BR
X1152
2 X768 2 X769
6312.0 6312.0
8 X13252
2.5 RT/BL
04/99
5133.0
F14
30A
F15
15A
6100.0
6
K6301w
FUEL PUMP RELAY
8 X6301
.5 RT/WS/GE
1210.17
F13
5A
1210.20
B6247
CHARCOAL FILTER
SHUT–OFF VALVE
2 X6247
1210.17
1210.20
X2233
.5 RT/WS/GE .5 RT/WS/GE
S6
ASC SWITCH
1 X2227
3450.1
.5 RT/WS/GE
A52
SLIP CONTROL
MODULE
(ABS/ASC)
1 X1175
1.5 RT/WS/GE
3450.1
M ROADSTER
WITH ASC
