BobsCNC Evolution Series - Z Spindle Mount Assembly; Required Wood Components

9
When a component has a T-Slot the nut is
always placed in the slot as shown. The
Machine Screw is threaded through the
adjoining component into to the nut and
tightened as noted above.
CAUTION This kit contains numerous small
components that pose a choking risk for small
children and pets. Keep kit pieces in a secure
location out of the reach or small children and pets.
Z Spindle Mount Assembly:
Required Wood Components
Part #
Description
Qty
Z1
Z Frame Mount Support
2
T-Slot
