Appendix ($130=1283)
Evolution 5 Firmware Values
Key
Value
Description
$0
10
(step pulse, usec)
$1
25
(step idle delay, msec)
$2
0
(step port invert mask:00000000)
$3
0
(dir port invert mask:00000000)
$4
0
(step enable invert, bool)
$5
1
(limit pins invert, bool)
$6
0
(probe pin invert, bool)
$10
1
(status report mask:00000011)
$11
0.01
(junction deviation, mm)
$12
0.002
(arc tolerance, mm)
$13
0
(report inches, bool)
$20
1
(soft limits, bool)
$21
0
(hard limits, bool)
$22
1
(homing cycle, bool)
$23
3
(homing dir invert mask:00000011)
$24
250
(homing feed, mm/min)
$25
2000
(homing seek, mm/min)
$26
250
(homing debounce, msec)
$27
5
(homing pull-off, mm)
$30
1000
Maximum spindle speed, RPM
$31
0
Minimum spindle speed, RPM
$32
0
Laser-mode enable, boolean
$100
80
(x, step/mm)
$101
80
(y, step/mm)
$102
400
(z, step/mm)
