BobsCNC Evolution Series - Evolution Washer Dimensions

155
$110
10000
(x max rate, mm/min)
$111
10000
(y max rate, mm/min)
$112
2000
(z max rate, mm/min)
$120
500
(X-axis acceleration, mm/sec^2)
$121
500
(Y-axis acceleration, mm/sec^2)
$122
500
(Z-axis acceleration, mm/sec^2)
$130
1283
(X-axis maximum travel, millimeters)
$131
610
(Y-axis maximum travel, millimeters)
$132
85
(Z-axis maximum travel, millimeters)
Evolution Washer Dimensions
Part number
Description
ID
OD
Thickness
(min)
Thickness (max)
H41
Eccentric Washer
0.453
0.750
0.059
0.063
H42
Bearing Fender Washer
0.250
0.750
0.060
0.090
H50
Idler Fender Washer
0.203
0.750
0.043
0.051
H57
Bearing Retainer Washer
0.172
0.050
0.050
0.080
H66
Small Shim Washer
0.256
0.500
0.028
0.035
