BobsCNC Evolution Series - Final Assembly; Wood Components (Included with Kit); Required Hardware

104
Final Assembly
Wood Components (Included with Kit)
Part #
Description
Qty
X9
Belt Retainer
Short
2
X10
Belt Retainer
Long
2
X3
Rail Stop
4
X11
Belt Adjusting
Plate
2
G6
Rail Stop
2
Required Hardware
Part #
Description
Qty
OO
Heat Shrink
Tubing
1
CB15
Pin Connector
1
H56
GT2 Belt
3
H82
Stress Proof
Steel X Rail
4
H53
Stress Proof
Steel Y Rail
2
H39
M6 x 30
Machine Screw
4
H60
M6 Nut
8
