X Frame Instructions
Required Wood Components
Part #
Description
Qty
X1
Rail Support
8
X2
Frame
Corner Brace
4
X4
Frame
Mid Support
4
EX4
Frame
Mid Support
1
EX5
Frame Side
Support
Front
2
X5
Frame Side
Support Rear
2
X6
Frame
End Support
2
X7
Wire
Harness
Support
2
