Gantry Assembly
Required Wood Components
Part #
Description
Qt
y
G1
Gantry
Frame
1
G2
Gantry Side
Support
4
G3
Gantry Cross
Brace
4
G4
Y Rail
Support
7
G5
Controller
Mount
1
G7
Gantry Back
Brace
2
G8
Gantry Back
Support
2
G9
Gantry
Top/Bottom
Brace
2
G10
Gantry Side
2
G11
Y Stepper
Motor Mount
1
