BobsCNC Evolution Series - Required Hardware

42
G12
Y Belt Idler
Mount
1
G13
Y Belt
Adjuster
1
G14
Gantry Side
Lower Brace
2
GA1
21mm Pulley
Gauge
1
Required Hardware
Part #
Description
Qty
H37
M3 X 10 Machine
Screws
12
H39
M6 X 30 Machine
Screws
8
H27
M2.5 x 16 Machine
Screws
6
H43
M2.5 Lock Nuts
6
H18
M6 Lock Nuts
8
H40
Eccentric Adjustment
Spacer
4
H41
Eccentric Washer
4
H42
Bearing Fender Washer
12
