Illustrated Step by Step Instructions
The Z Carriage Assembly holds the Router securely in a carriage that travels
up and down the Z-axis on a set of Rails. These first steps will show you
how to build the Spindle (Router) Mount.
NOTE: The Z Frame has alignment marks that are used to snug the SG20U
Bearings to the Rails and later to tram the Router. When assembling the Z
Carriage, it is important that the adjustment marks face toward the Spindle
Mount as shown in the following photos.
