Y Carriage Assembly
Required Wood Components
Part #
Description
Qty
Y1
Z Stepper
Motor Mount
1
Y2
Rail Top
Support
1
Y3
Bearing
Retainer Plate
1
Y4
Y Carriage
Frame
1
Y5
Y Carriage
Side Support
2
Y6
Belt Retainer
1
