FIRE AND ALARM CONSOLE
8
Table 2 Indicator ‘ALARM’ (red)
State Indication
Norm Off
SILENT ALARM Blink with frequency 2 HZ
ALARM Blink with frequency 1 HZ
INTRUSION ALARM Blink with frequency 4 HZ
Table 3 Indicator ‘FIRE’ (red)
State Indication
Norm Off
FIRE Blink with frequency 2 HZ
ATTENTION On for ¼ с frequency 1 HZ
Table 4 Indicator ‘TROUBLE’ (red)
State Indication
Norm Off
NOT ARMING Blink with frequency 1 HZ
LOOP OPEN CIRCUIT
LOOP SHORT CIRCUIT
CONFIGURATION ERROR
OPEN RELAY OUTPUT
RELAY OUTPUT SHORT CIRCUIT
BATTERY FAILED
AC POWER FAILED
POWER FAILED
On for 1/8 с frequency 1 HZ
Table 5 Indicator ‘FAULT’ (red)
State Indication
Norm Off
DISCONNECTED ALARM LOOP
RELAY DISCONNECTED
2-WIRE LINE SHORT CIRCUIT
2-WIRE LINE TROUBLE
ENCLOSURE TAMPERING
Blink with frequency 2 HZ
Table 6 Inner sound notificator
Event or state Content
Norm Notificator off
Button pressed
Short sound signal.
Notificator is off, if alarm was on
Successful operation
Two short signals (signal ‘Confirmation’)
Unsuccessful operation Long sound signal (signal ‘Error’)
‘Intrusion alarm’ or
‘Silent alarm’ messages are received
Sound signal ‘Alarm’ (interrupted sound signal with
signal duration approximately equal to the pause
duration)
‘Fire prealarm’ message is received
Sound signal ‘Attention’ (periodic sequence of
alternate short and long signals)
‘Fire alarm’ message is received
Sound signal ‘Fire alarm’ (interrupted sound signal
with long signals and short pauses)
‘Tamper alarm’, ‘device restart’ messages are
received, disconnection the device is occurred
Sound signal ‘Break’
(interrupted high frequency sound signal)
‘Loop trbl open’, ‘loop trbl short’, ‘fire trouble’,
‘2wire line open’, ‘2wire line short’, ‘2wire line
short’, ‘power failed’, ‘battery failed’, ‘AC power
failed’ messages are received
Sound signal ‘Fault’ (interrupted sound signal with
short beeps and long pauses (2,5 s) between
signals)
