15
IP connection
For more information regarding adding ONVIF and VISCA over IP cameras to be controlled by the
keyboard, please see the section on Keyboard IP Configuration
Make Serial Port Connection
The controller supports serial RS232/RS422 and IP Cross protocol mix-control. It allows you to use
RS232/RS422/IP control on one controller to control cameras (Protocol support: VISCA, PELCO D/P, ONVIF,
VISCA over IP) in a single system.
IP port to network switch
•
•
o
o
RS232 Connection
• RS232 Connection
•
To Next Page
