37
buttons which are not selected will light in red. You can select a camera by pressing its
respective CAMERA button (lit in red).
▪ The tally lamp of the camera receiving a command from the TALLY/CONTACT connector
lights. *
▪ On Air - Displays the tally input lamp corresponding to the number of the camera with tally
input ON.
o ON AIR TALLY mode: The following actions are performed for the number that is input from the
TALLY/ CONTACT connector only while receiving the commands.
▪ The corresponding CAMERA button lights in red.
▪ A camera can be selected arbitrarily. Selecting a CAMERA button lit in red will make it flash in
red and yellow alternately.
▪ The tally lamp of the camera receiving a command from the TALLY/CONTACT connector
lights. *
• Command Select
o Standard - Sets the input/output method to STANDARD method. The camera numbers and input/output
pin numbers have a 1:1 correspondence.
▪ If the unit and cameras are connected by serial connection, cameras 1 to 7 correspond to
input/outputs 1 to 7.
▪ If the unit and cameras are connected by LAN connection, cameras 1 to 10 in group 1
correspond to input/outputs 1 to 10.
o Expand - Handles camera numbers as binary numbers.
▪ Tally input numbers 8 and higher in a serial connection are ignored. In this case, the response is
equivalent to no input.
▪ Numbers in a LAN connection, corresponding to cameras 1 to 10 in groups 1 to 10, are handled
as the numbers 1 to 100. Tally input numbers 101 and higher are ignored. In this case, the
response is equivalent to no input.
• Camera Link - Turns tally lamp control on/off. The tally lamp control operation varies depending on the
combination of the SETTING and CAMERA LINK settings.
Password Setting
• Old Password: Enter the current password
• New Password: Enter the password you would
like to set
• Confirm: Enter the new password again to
confirm
• Save: Select this to apply the password. “OK”
will appear, confirming that the new password
has been applied
