LCD Screen Setting Tree
SETUP Button CAMXXX 001-255
TITLE
Baud Rate 2400, 9600, 19200, 38400
Port RS422 / RS232
PELCO-D Baud Rate 2400, 9600, 19200, 38400
PELCO-P Baud Rate 2400, 9600, 19200, 38400
IP Address User entry using keypad
User Name User entry using keypad
Password User entry using keypad
Port User entry using keypad
IP Address User entry using keypad
Payload OFF / ON
Port 52381 / 1259 / User
EXIT
KEYBOARD SETTING TYPE STATIC, DHCP
IP Address User entry using keypad
Subnet Mask User entry using keypad
Gateway User entry using keypad
Exit User entry using keypad
Button Light Level 0, 1, 2
ASSIGNED KEY
F1, F2, F3, F4, F5, F6
Home, P/T Reset, Power, Mute,
Picture Freeze, Picture Flip, Picture
L/R Reverse, None
Exit
Factory Default Yes?, No?
Setting Input, Output
Tally Mode Normal, On Air
Command Sel Standard, Expand
Camera Link On, Off
Exit
Old Password User entry using keypad
New Password User entry using keypad
Confirm User entry using keypad
Save
Exit
Joystick Zoom ON, OFF
MODEL INFO IP Address, FW Version, Exit
Payload Header OFF / ON
Port 52381 / 1259 / User
PTZ Controller
Video Router Switch
Exit
EXIT
SEARCH button VISCA-IP Start Search Yes (Search Results)
No&Exit
ONVIF-IP Start Search Yes (Search Results)
No&Exit
INQUIRY button VISCA-IP CAM, Call, Exit
ONVIF-IP CAM, Call, Exit
CONTROL MODE
CAMERA SETTING
IP CONFIGURATION
GPI I/O
PASSWORD SETTING
VISCA IP SETTING
User entry using keypad
VISCA
ONVIF
VISCAIP
