Operation mode 530,532,554
22 - Warning V-belt
Warning of Operation Mode 581 of V-belt moni-
toring.
23 - Timer 1
The selected Operation Mode Timer 1 790 gen-
erates an output signal of the function.
24 - Timer 2
The selected Operation Mode Timer 2 793 gen-
erates an output signal of the function.
25 - Warning Mask
Message of the configurable parameter Create
Warning Mask 536.
26 - Warning, Application
Warning application is signaled. Display of the
actual value is affected via parameter Warnings
27 - Warning Mask, Application
Message of the configurable parameter Create
Warning Mask Application 626.
28 -
Warning, gen + Warning,
Application
Warning or warning application is signaled.
29 -
Warn. Mask, gen + Warn.
Mask, Appl.
Message of configurable parameters Create
Warning Mask 536 and Create Warning Mask
626.
Magnetic field has been impressed.
41 - Brake release
Activation of a brake unit depending on the Op-
eration Mode 620 for the starting behavior, Op-
eration Mode
630 for the stopping behavior or
the configured brake control system.
43 - External Fan
The Switch-On Temperature 39 has been
reached.
50 - Synchronization Fault
1)
The phase error of the index control exceeded
the Warning limit 597.
51 - Signal Fault
1)
Index signal period too short during index con-
trol.
56 - Phasing Done
2)
Message of phasing function. For positioning in
combination with the function of the electronic
gear, the value
Phasing: Offset 1125 was
57 - In Gear
1) 2)
Synchronization of the electronic gear is reached.
The slave drive is engaged and operates at a
synchronous angle with the master.
58 - Position comparator
2)
The current actual value is in the range between
Switch-on position 1243 and Switch-off position
1244 of the position comparator. The adjusted
value of the parameter
Hysteresis 1245 is con-
59 - Homing Done
2)
A reference travel operation was started and the
reference position for positioning was set.
60 - Target Position Reached
Reference orientation 469 of axle positioning
was reached or
Target position / Distance 1202 of a position-
ing
2)
operation was reached (the current act.
position is within the range set in parameter
Target window 1165 for a minimum period of
1166).
61 -
Warning Deviation of Posi-
tion
2)
The contouring error monitoring Warning
Threshold
1105 was exceeded.
62 -
Motion-Block Digital Sig-
nal 1
2)
Message on status of a travel order during a
positioning operation. The conditions set for pa-
rameter
Digital Signal 1 1218 were fulfilled.
“Start”, “Reference value reached” and “End”
of a
travel order were evaluated.
06/13 Operating Instructions ACU 181
