21.4 Warning Status and Warning Status Application
The current warning is displayed by a message in the warning status and can be
used for an early message of a critical operational condition. If a warning is present,
this is indicated by the flashing red LED and the display f
ield WARN of the control
unit. If several warnings are present, the warning status is displayed as the sum of
the individual warning codes.
The warning masks created through parameters Create warning mask 536 and Cre-
ate warning mask application
626
have no influence on the warnings displayed. Via
the actual value parameters Warning 269, Application Warnings 273, Warning
status
356 (in error environment) and Warning status application 367 (in error envi-
ronment), all warnings present at the time of the error are always displayed.
Coding of the warning status
Warning code Abbreviation for the warning
Meaning of code displayed by parameter Warning status 356:
Code Warning Status
A 00 00 - No warning message present.
A 00 01 Ixt Frequency inverter overloaded (A0002 or A0004).
A 00 02 IxtSt
Overload for 60 s relative to the nominal output of the frequen-
cy inverter.
A 00 04 IxtLt
Short-time overload for 1 s relative to the nominal output of the
frequency inverter.
A 00 08 Tc
Max. heat sink temperature T
K
of 80 °C less the Warning Limit
Heat Sink Temp.407 reached.
A 00 10 Ti
Max. inside temperature T
i
of 65 °C less the Warning Limit
Inside Temp. 408 reached.
A 00 20 Lim
The controller stated in Controller status 275 limits the refer-
ence value.
A 00 40 INIT Frequency inverter is being initialized.
A 00 80 PTC
Warning behavior according to parameterized Operation mode
Motor temp. 570 at max. motor temperature T
Motor
.
A 01 00 Mains
reports a phase failure.
A 02 00 PMS
Motor protection switch parameterized in Operation mode 571
tripped.
A 04 00 Flim
The Maximum frequency 419 was exceeded. The frequency
limitation is active.
A 08 00 A1
The input signal MFI1A is lower than 1 V / 2 mA according to
the operation mode for the
453.
A 10 00 A2
The input signal is lower than 1 V / 2 mA according to the op-
eration mode for the Error/warning behavior 453.
A 20 00 SYS
A slave on the system bus reports a fault; warning is only rele-
vant with the EM-SYS option.
A 40 00 UDC
The DC link voltage has reached the type-dependent minimum
value.
In Warning status application 367, a warning is present.
