14.6.2 JOG frequency
The JOG function forms part of the functions for controlling the drive mechanism via
the control unit. Use the arrow keys to change the JOG frequency within the function.
The frequency of the output signal is set to the entered value if the FUN key is
pressed. The drive starts and the machine turns at the set JOG frequency 489
. If
the JOG frequency has been changed using the arrow keys, this value is stored.
Parameter
Settings
No. Description Min. Max. Fact. sett.
489 JOG frequency -999.99 Hz 999.99 Hz 5.00 Hz
14.6.3 Fixed Percentages
The four percentage values define reference values which are selected via the Fixed
percent change-over 1 75 and Fixed percent change-over 2 76. The Reference per-
centage source
476 defines the addition of the various sources in the reference per-
centage channel.
Parameter
Settings
No. Description Min. Max. Fact. sett.
520 Fixed percentage 1 -300.00 % 300.00 % 0.00 %
521 Fixed percentage 2 -300.00 % 300.00 % 20.00 %
522 Fixed percentage 3 -300.00 % 300.00 % 50.00 %
523 Fixed percentage 4 -300.00 % 300.00 % 100.00 %
By combining the logic states of the fixed percentage change-over modes 1 and 2,
fixed frequencies 1 through 4 can be selected:
Fixed Percentage Control
Fixed percentage
change-over 1 75
Fixed percentage
change-over 2 76
Function / active fixed value
0
0
Fixed Percentage 1 520
1 0
Fixed Percentage 2
521
1 1
Fixed Percentage 3
522
0 1
Fixed Percentage 4
523
0 = contact open 1 = contact closed
162 Operating Instructions ACU 06/13
