14.11 PWM-/repetition frequency input
The use of a PWM (pulse-width modulated) frequency signal completes the various
possibilities of the reference value specification. The signal at
one of the available
digital inputs is evaluated according to the selected Operation mode 496.
PWM frequencies in the range between 50 Hz and 150 kHz can be evaluated.
Operation mode 496
Function
0 - Off The PWM signal or repetition frequency is zero.
2 - PWM S2IND, 0 - 100%
PWM signal capture on terminal X210A.4.
0 … 100% of Maximum reference percentage 519
or 0 … 100% of Maximum frequency 419.
3 - PWM S3IND, 0 - 100%
PWM signal capture on terminal X210A.5.
0 … 100% of Maximum reference percentage 519
or 0 … 100% of Maximum frequency 419.
6 - PWM S6IND, 0 - 100%
PWM signal capture on terminal X210B.1.
0 … 100% of Maximum reference percentage 519
or 0 … 100% of
Maximum frequency
419.
12 - PWM S2IND, -100 - 100%
PWM signal capture on terminal X210A.4.
-100 … 100% of Maximum reference percentage
519 or -100 … 100% of
Maximum frequency
419.
13 - PWM S3IND, -100 - 100%
PWM signal capture on terminal X210A.5.
-100 … 100% of Maximum reference percentage
519 or -100 … 100% of Maximum frequency 419.
16 - PWM S6IND, -100 - 100%
PWM signal capture on terminal X210B.1.
-100 … 100% of Maximum reference percentage
519 or -100 … 100% of Maximum frequency 419.
21 -
S2IND
Single evaluation pos.
Repetition frequency input on terminal X210A.4.
One edge of the frequency signal is evaluated with
a positive sign.
22 -
S2IND
Double evaluation pos.
Repetition frequency input on terminal X210A.4.
Both edges of the frequency signal are evaluated
with a positive sign.
31 -
S3IND
Single evaluation pos.
Repetition frequency input on terminal X210A.5.
One edge of the frequency signal is evaluated with
a positive sign.
32 -
S3IND
Double evaluation pos.
Repetition frequency input on terminal X210A.5.
Both edges of the frequency signal are
evaluated
with a positive sign.
61 -
S6IND
Single evaluation pos.
Repetition frequency input on terminal X210B.1.
One edge of the frequency signal is evaluated with
a positive sign.
62 -
S6IND
Double evaluation pos.
Repetition frequency input on terminal X210B.1.
Both edges of the frequency signal are evaluated
with a positive sign.
121 to 162
Repetition Frequency Input. Operation modes 21
to 62 with evaluation of the fre
quency signal, but
with a negative sign.
If a digital input is configured as a PWM or repetition frequency input, this input cannot
be used for other functions.
Check the link of the digital inputs to other functions.
